Automatic RCYD-5 Suspended Cross Magnetic Iron Separator for Belt Deironing
Product Details:
| Place of Origin: | Shandong, China |
| Brand Name: | PHOENIX MACHINERY |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $2,500.00/sets 1-4 sets |
|
Detail Information |
|||
| Condition: | New | Machine Type: | Automatic Magnetic Iron Remover |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Hot Product 2023 | Warranty Of Core Components: | 1 Year |
| Core Components: | PLC, Engine, Bearing, Gearbox, Motor | Warranty: | 1 Year |
| Weight (KG): | 750 KG | Power (kW): | 1.5 |
| Key Selling Points: | Easy To Operate | Showroom Location: | None |
| Applicable Industries: | Energy & Mining | Applicable Belt Width (mm): | 500 |
| Suspension Height (mm): | 150 | Magnetic Field Intensity (>mt): | 60 |
| Material Depth (≤m): | 80 | Applicable Belt Speed (≤m/s): | 4.5 |
| Magnetic Field Intensity: | Strong Magnetic Separator | Name: | Iron Suction |
| Product Name: | Small Size Belt Conveyor Magnetic | Model: | RCYD-5 |
| Feeding Method: | Lower Feed Magnetic Separator | ||
Product Description
Products Description
Specification
Model | Applicable belt width (mm) | Suspension height (mm) | Magnetic field intensity (>mt) | Material depth (≤m) | Driving power (kw) | Applicable belt speed (≤m/s) | Weight (kg) |
RCYD-5 | 500 | 150 | 60 | 80 | 1.5 | 4.5 | 750 |
RCYD-6 | 600 | 175 | 60 | 120 | 1.5 | 920 | |
RCYD-6.5 | 650 | 200 | 70 | 150 | 2.2 | 1200 | |
RCYD-8 | 800 | 250 | 70 | 200 | 2.2 | 1400 | |
RCYD-10 | 1000 | 300 | 70 | 250 | 3 | 1900 | |
RCYD-12 | 1200 | 350 | 70 | 300 | 4 | 2650 | |
RCYD-14 | 1400 | 400 | 70 | 350 | 4 | 3700 | |
RCYD-16 | 1600 | 450 | 70 | 400 | 5.5 | 4950 | |
RCYD-18 | 1800 | 500 | 72 | 450 | 7.5 | 6100 | |
RCYD-20 | 2000 | 550 | 72 | 500 | 11 | 8900 |
Packing Delivery
1. Outside package: Standard marine export plywood cases.
2. Inner package: Stretch film and plastic film for humidity.
We can package according to your requests
Product Name | Self Dumping Magnetic Separator Belt Magnetic Belt Separator For Removing Iron |
Brand | PHOENIX EQUIPMENT |
Customized | color, logo, voltage |
MOQ | 1 set |
Package | plywood wooden box |
Payment terms | Alibaba Trade Assurance, T/T, Alipay |
Use | The cutting machine can be used for Chipboard , fiberboard , multilayer board , ecologic board , oak board , finger joint board ,wheat straw board , solid wood board , PVC board,aluminum honeycomb board , etc |
