Wood Panels Cutting Machine with Heavy Duty Design and Automatic Function MJB318
Product Details:
| Place of Origin: | Shandong, China |
| Brand Name: | PHOENIX MACHINERY |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $6,200.00/pieces 1-3 pieces |
|
Detail Information |
|||
| Condition: | New | Type: | Wood Veneer Clipper Machine, Wood Based Panels Machinery |
|---|---|---|---|
| Dimension(L*W*H): | 4600*1380*1900mm | Power (kW): | 4.37kw |
| Weight (KG): | 3000 Kg | Applicable Industries: | Manufacturing Plant, Home Use, Construction Works , Other, Plywood Machinery |
| Warranty: | 1 Year | Key Selling Points: | Easy To Operate |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor, Gearbox | Use: | MDF Production |
| Name: | Veneer Clipper | Product Name: | Wood Veneer Clipper Machine |
| Style: | Horizontal | Application: | Panels Wood Cutting Machine |
| Max.cuttinglength: | 3180mm | Max.cuttingthickness: | 60mm |
| Knife Size: | 3250*140*12.7mm | Airpressure: | 0.45-0.75Mpa |
| Weight: | 3000kg | ||
Product Description
Products Description
Specification
Model | MJB150 | MJB268 | MJB318 | MJB418 |
Max.cuttinglength | 1480mm | 2680mm | 3180mm | 4180mm |
Max.cuttingthickness | 60mm | 60mm | 60mm | 60mm |
Knifesize | 1550*140*12.7mm | 2750*140*12.7mm | 3250*140*12.7mm | 4250*140*12.7mm |
Airpressure | 0.45-0.75Mpa | 0.45-0.75Mpa | 0.45-0.75Mpa | 0.45-0.75Mpa |
Motorpower | 4.37kw | 4.37kw | 4.37kw | 4.37kw |
Overalldimensions | 3000*1380*1900mm | 4100*1380*1900mm | 4600*1380*1900mm | 5600*1380*1900mm |
Weight | 2000kg | 2500kg | 3000kg | 3600kg |
Packing Delivery
1. Outside package: Standard marine export plywood cases.
2. Inner package: Stretch film and plastic film for humidity.
We can package according to your requests
Product Name | veneer clipper veneer cutting guillotine |
Brand | PHOENIX EQUIPMENT |
Customized | color, logo, voltage |
MOQ | 1 set |
Package | plywood wooden box |
Payment terms | Alibaba Trade Assurance, T/T, Alipay |
Usage | Used for cutting various types of boards such as thin wooden boards, veneer, paper, etc |
