Woodworking 400C Multi Functional Machine for Woodworking Efficiency in Garment Shops
Product Details:
| Place of Origin: | Shandong, China |
| Brand Name: | PHOENIX EQUIPMENT |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $2,800.00/acres 1-4 acres |
| Packaging Details: | 1. Outside package: Standard marine export plywood cases. <br>2. Inner package: Stretch film and plastic film for humidity. <br>We can package according to your requests<br>Port<br>Qingdao port |
| Supply Ability: | 100 Acre/Acres per Month |
|
Detail Information |
|||
| Condition: | New | Machine Type: | Multifunctional Combination Machine |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | PLC, Engine, Gearbox, Motor, Pressure Vessel, Gear, Pump | Warranty: | 1 Year |
| Weight (KG): | 490 KG | Power (kW): | 4 |
| Key Selling Points: | Automatic | Showroom Location: | United Kingdom, United States, Italy, France, Germany |
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Restaurant, Home Use, Construction Works , Other, Advertising Company | Style: | Multi Functional Combine Wood Working Machine |
| Name: | Carpenter Combined Machine | Brand: | PHOENIX EQUIPMENT |
| Working Form: | Fully Automatic | Working Tables: | 400x1800mm |
| Cutterblock Diameter: | 70mm | 3-phase Motor Power: | 4,0 - 3,0kw |
| Weight: | 385kg | Wescott(Chuck): | 16mm |
| Cutterblock Rotation Speed: | 5700r.p.m | ||
Product Description
Products Description
Specification
Planer | Unit | 400C |
Working tables | mm | 400x1800 |
Cutterblock diameter | mm | 70 |
Cutterblock rotation speed | r.p.m | 5700 |
N. of knives | n° | 3 |
knives dimensions | mm | 400x20x3 |
Max table adjustement | mm | 4 |
Working table | mm | 400x760 |
Feed speed | m/1' | 7 |
Max. working height | mm | 220 |
Min. working height | mm | 4 |
Cutterblock rotation speed | r.p.m | 5700 |
Max. cutting depth | mm | 4 |
Working table | mm | 250x500 |
Longitudinal stroke | mm | 205 |
Trasversal stroke | mm | 95 |
Vertical stroke | mm | 90 |
Churck | mm | 16 |
Churck rotation speed | r.p.m | 5700 |
Service wrenches | * | * |
Mortiser chuck | * | * |
Guards on mortiseur chuck | * | * |
3 pcs. planing knives | * | * |
Planer guide | * | * |
Bridge sefety hood on planer | * | * |
3-phase motor power | HP - KW | 4,0 - 3,0 |
Weight | Kg | 385 |
Single-phase motor | HP - KW | 5,5 - 4,0 |
Increasing 3-phase motor | HP - KW | 4,0 - 3,0 |
Wescott(Chuck) | mm | 16 |
Packing Delivery
1. Outside package: Standard marine export plywood cases.
2. Inner package: Stretch film and plastic film for humidity.
We can package according to your requests
Product Name | Woodworking Planer Machine Prices Italian Technology Combination Woodworking Machine |
Brand | PHOENIX EQUIPMENT |
Customized | color, logo, voltage |
MOQ | 1 set |
Package | plywood wooden box |
Payment terms | Alibaba Trade Assurance, T/T, Alipay |
Usage | The machine is for surface polishing and fixed thick sanding ,suitable for timber, wood panels, block board, cement fiberboard,insulation panels, ceramic fiber, glass fiber, wall panels, wood products and other artifacts. |
