4kw Automatic Sliding Table Wood Shaper Machines for Woodworking MX5117A/MX5117B
Product Details:
| Place of Origin: | Shandong, China |
| Brand Name: | PHOENIX MACHINERY |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $1,680.00/sets 1-9 sets |
| Packaging Details: | 1. Outside package: Standard marine export plywood cases.<br>2. Inner package: Stretch film and plastic film for humidity.<br>We can package according to your requests |
| Supply Ability: | 100 Set/Sets per Month |
|
Detail Information |
|||
| Condition: | New | Spindle Diameter(mm): | 35 Mm |
|---|---|---|---|
| Max.Working Thickness(mm): | 120 Mm | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | New Product 2023 |
| Warranty Of Core Components: | 1 Year | Core Components: | PLC, Motor |
| Voltage: | 380v/220v, Customized | Dimension(L*W*H): | 1600*780*950mm |
| Power (kW): | 4 | Warranty: | 1 Year |
| Key Selling Points: | Easy To Operate | Application: | Wood Furniture Production |
| Weight (KG): | 400 Kg | Applicable Industries: | Machinery Repair Shops, Wood Furniture Factory, Wooden Door Factory |
| Showroom Location: | None | Model: | MX5117A/MX5117B |
| Product Name: | Sliding Table Vertical Shaft | Keywords: | Wood Spingle Moulder |
| Function: | Milling Wood | Key Word: | Spindle Moulder Machine |
| Usage: | Curve Milling | Platform Size: | 1600*1480mm |
| Maximum Machining Thickness: | 120mm | Maximum Spindle Lifting Height: | 200mm |
| Port: | Qingdao | ||
Product Description
Products Description
Specification
Model | MX5117B | MX5117A |
Platform size | 1600*1480mm | 1600*1480mm |
Spindle diameter | 35mm | 35mm |
Spindle speed | 6000/8000/10000r/min | 6000/8000/10000r/min |
Maximum machining thickness | 120mm | 120mm |
Maximum spindle lifting height | 200mm | 200mm |
Spindle power | 4KW | 5.5KW |
Machine size | 1600*1480*950mm | 1600*1480*950mm |
Machine weight | 400 KG | 400 KG |
Packing Delivery
1. Outside package: Standard marine export plywood cases.
2. Inner package: Stretch film and plastic film for humidity.
We can package according to your requests
Product Name | Woodworking sliding table spindle moulder machine solid wood MDF door milling machine spindle moulding machine |
Brand | PHOENIX EQUIPMENT |
Customized | color, logo, voltage |
MOQ | 1 set |
Package | plywood wooden box |
Payment terms | Alibaba Trade Assurance, T/T, Alipay |
Applicable Industries | Manufacturing Plant, Wood furniture factory, Wooden door factory |
