MB9016A Wood Profile Line Moulding Machine for Smooth and Accurate Door Frame Profiles
Product Details:
| Place of Origin: | Shandong, China |
| Brand Name: | PHOENIX EQUIPMENT |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $2,693.00/sets 1-1 sets |
| Packaging Details: | 1. Outside package: Standard marine export plywood cases.<br>2. Inner package: Stretch film and plastic film for humidity.<br>We can package according to your requests |
| Supply Ability: | 100 Set/Sets per Month |
|
Detail Information |
|||
| Condition: | New | Shaft Number: | Single |
|---|---|---|---|
| Spindle Diameter(mm): | 40 Mm | Max.Working Thickness(mm): | 120 Mm |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2023 | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor | Dimension(L*W*H): | 950*800*1250 |
| Power (kW): | 5.5kw+0.75KW | Warranty: | 1 Year |
| Key Selling Points: | Easy To Operate | Application: | Door And Window Cover Line Top Line Making |
| Weight (KG): | 780 Kg | Applicable Industries: | Building Material Shops, Machinery Repair Shops, Manufacturing Plant |
| Showroom Location: | None | Product Name: | Wood Door Line Milling Making Machine |
| Name: | Surface Molding Machine | Keywords: | Wood Line Moulding Machine |
| Working Width: | 8~160mm | Working Thickness: | 10~120mm |
| Feeding Speed: | 0.1~12m/min | Spindle Diameter: | 40mm |
| Installation Tools: | 40*115*160 | ||
Product Description
Products Description
Specification
Model | MB9016A |
Working width(mm) | 8~160 |
Working thickness | 10~120mm |
Feeding speed | 0.1~12m/min |
Spindle speed | 7000r/min |
Spindle diameter | 40mm |
Motor power | 5.5kw+0.75KW |
Installation tools | 40*115*160 |
Dimension(mm) | 950*800*1250 |
Packing Delivery
1. Outside package: Standard marine export plywood cases.
2. Inner package: Stretch film and plastic film for humidity.
We can package according to your requests
Product Name | MB9016A Hot Sale woodworking machinery High Precision High speed surface wood profiles line moulding moulder machine |
Brand | PHOENIX EQUIPMENT |
Customized | color, logo, voltage |
MOQ | 1 set |
Package | plywood wooden box |
Payment terms | Alibaba Trade Assurance, T/T, Alipay |
Usage | used for processing all kinds of wood lines and decorative mouldings. It is suitable for home decoration and wooden door industry,wood products processing, wooden musical instruments, wooden photo frame production. |
