Small Material Splitter with High Speed Wooden Square Multi Blade Saw and 11kW Power
Product Details:
| Place of Origin: | Shandong |
| Brand Name: | Phoenix Equipment |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $4,800.00/sets 1-1 sets |
| Packaging Details: | 1. Outside package: Standard marine export plywood cases.<br>2. Inner package: Stretch film and plastic film for humidity.<br>We can package according to your requests |
| Supply Ability: | 100 Set/Sets per Month |
|
Detail Information |
|||
| Condition: | New | Type: | Circular Saw, Rip Saw |
|---|---|---|---|
| Use: | Woodworking, Precision Cut | Style: | Horizontal |
| Voltage: | 380V | Dimension(L*W*H): | 1750*850*1550mm |
| Warranty: | 1 Year | Application: | Manufacturing Plant, Farms, Home Use, Construction Works, Building Material Shops, Single Blade Rip Saw Machine, Wood Saw Machine, Furniture |
| Weight (KG): | 900 KG | Power (kW): | 11 |
| Key Selling Points: | Easy To Operate, Multiple Cuts | Applicable Industries: | Building Material Shops, Manufacturing Plant, Farms, Home Use, Retail, Construction Works |
| Marketing Type: | New Product 2023 | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor | Name: | Multi-blade Rip Saw Machine |
| Function: | Wood Cuttiing | Usage: | Multi-blade Wood Sawing Machine |
| Working Length: | 200-4000mm | Working Width: | 10-200mm |
| Working Thickness: | 10-80mm | Total Power: | 12.84kW |
| Port: | Qingdao | ||
Product Description
Products Description
Specification
Model | MJ200C | MJ200D |
Working length | 200-4000mm | 80-4000mm |
Working width | 10-200mm | 5-200mm |
Working thickness | 10-80mm | 5-60mm |
Feed motor power | 1.1kW (stepless) | 1.1kw(stepless) |
Feed speed | 4-20m/min | 4-20m/min |
Spindle motor power | 11kW | 11kW |
Spindle speed | 3600r/min | 3600r/min |
Max blade diameter | Φ230mm | Φ230mm |
Extraction outlet size | Φ125mm | Φ125mm |
Spindle diameter | Φ35mm | Φ35mm |
Lifting motor power | 0.37kW | 0.37kW |
Beam lift motor power | 0.37kW | 0.37kW |
Total Power | 12.84kW | 12.84kW |
Air Pressure | 0.6Mpa | 0.6mpa |
Overall size | 1750*850*1550mm | 1750*850*1550mm |
Weight | 900kg | 900kg |
Packing Delivery
1. Outside package: Standard marine export plywood cases.
2. Inner package: Stretch film and plastic film for humidity.
We can package according to your requests
Product Name | 200mm Multiple Blade Rip Saw for Solid Wood Saw Machine |
Brand | PHOENIX EQUIPMENT |
Customized | color, logo, voltage |
MOQ | 1 set |
Package | plywood wooden box |
Payment terms | Alibaba Trade Assurance, T/T, Alipay |
Usage | Various wooden boards, density board side edges |
